Original Cartilage and Evidence of DNA Preserved in 75 Million-Year-Old Baby Dinosaur

duck-billed dinosaur in prehistoric woodland

Researchers from the Chinese Academy of Sciences and North Carolina State University have found evidence of preserved fragments of proteins and apparent chromosomes within isolated cell-like microstructures in cartilage from a baby duckbilled dinosaur. The findings further support the idea that these original molecules can persist for tens of millions of years.

Microscopic analyses of skulls from a clutch of eggs, embryos, hatchlings and nestlings belonging to Hypacrosaurus – a type of duckbilled dinosaur that lived in what is now Montana during the late Cretaceous period – were conducted by Alida Bailleul, a paleontologist from the Chinese Academy of Sciences and corresponding author of a paper describing the work. She noticed structures within certain tissues that were consistent with chondrocytes, or cartilage cells, and within these were internal structures resembling nuclei and chromosomes.

“The skull bones of baby dinosaurs are not fused when they hatch, but instead, some of them have cartilaginous plates that fuse later as bone forms in the spaces between them,” Bailleul says. “Seeing exquisitely preserved microscopic structures that resembled the specific cell types found only in cartilage, and which would have been present in the living organism in these tissues, led us to hypothesize that cellular preservation may have extended to the molecular level.”

Bailleul, at China’s Institute of Vertebrate Paleontology and Paleoanthropology, led an international team to determine whether these original molecules had preserved over time. The team included Mary Schweitzer, professor of biology at NC State with a joint appointment at the North Carolina Museum of Sciences, as well as other researchers from Canada and the U.S.

The team performed immunological and histochemical analyses of tissues from the 75-million-year-old hatchling skull, comparing the results to those from an emu skull at a similar stage of development.

“Bird skulls ossify, or harden, in the same pattern as this hadrosaur’s skull would have, and primitive birds (ratites) like emus are the closest relatives we have alive today to non-avian dinosaurs,” Schweitzer says.

The cartilaginous tissues and chondrocytes from the dinosaur skull reacted with antibodies to collagen II, but the surrounding bone did not react with collagen II antibodies. This is significant because collagen II is found only in cartilage, while collagen I dominates in bone. Comparing the results to the emu confirmed the findings.

“These tests show how specific the antibodies are to each type of protein, and support the presence of collagen II in these tissues,” Schweitzer says. “Additionally, bacteria cannot produce collagen, which rules out contamination as the source of the molecules.”

The researchers also tested the microstructures for the presence of chemical markers consistent with DNA using two complementary histochemical stains that bind to DNA fragments within cells. These chemical markers reacted with isolated cartilaginous cells, supporting the idea that some fragmentary DNA may remain within the cells.

“We used two different kinds of intercalating stains, one of which will only attach to DNA fragments in dead cells, and the other which binds to any DNA,” Schweitzer explains. “The stains show point reactivity, meaning they are binding to specific molecules within the microstructure and not smeared across the entire ‘cell’ as would be expected if they arose from bacterial contamination.”

“Although bone cells have previously been isolated from dinosaur bone, this is the first time that cartilage-producing cells have been isolated from a fossil,” Bailleul says. “It’s an exciting find that adds to the growing body of evidence that these tissues, cells and nuclear material can persist for millions – even tens of millions – of years.”

The work appears in National Science Review and is supported by the National Science Foundation, the Packard Foundation and the Chinese Academy of Sciences.


Note to editors: An abstract follows.

“Evidence of proteins, chromosomes and chemical markers of DNA in exceptionally preserved dinosaur cartilage”

DOI: 10.1093/nsr/nwz206

Authors: Alida M. Bailleul, Chinese Academy of Sciences; Wenxia Zheng, Mary Schweitzer, North Carolina State University; John R. Horner, Chapman University; Brian Hall, Dalhousie University, Canada; Casey Holliday, University of Missouri
Published: National Science Review

A histological ground-section from a duck-billed dinosaur nestling(Hypacrosaurus stebingeri) revealed microstructures morphologically consistent with nuclei and chromosomes in cells within calcified cartilage. We hypothesized that this exceptional cellular preservation extended to the molecular level, and had molecular features in common with extant avian cartilage. Histochemical and immunological evidence supports in situ preservation of extracellular matrix components found in extant cartilage, including glycosaminoglycans and collagen type II. Furthermore, isolated Hypacrosaurus chondrocytes react positively with two DNA intercalating stains. Specific DNA staining is only observed inside the isolated cells, suggesting endogenous nuclear material survived fossilization. Our data support the preservation of calcified cartilage at the molecular level in Mesozoic material, and suggest that remnants of once-living chondrocytes, including their DNA, may preserve for millions of years.

This post was originally published in NC State News.
